Train Control Systems (TCS) 1530 | WOW101-Diesel | HO Scale

Description

  • CD-Quality Sound: TCS’ world-renowned CD-quality sound. 16 Bits of resolution at 44.1kHz sample rate.
  • Back EMF Load Compensation: Provides superior slow speed control and high performance under load.
  • Quiet Drive: Super-quiet motor control for “buzz” free motor performance.
  • Variable Momentum: Allows you to make custom acceleration and deceleration curves.
  • Incandescent Bulb Support: This decoder can be used with 12 Volt bulbs.
  • Function Remapping: Buttons 0 through 12 may be used to control the lighting functions of this decoder.
  • Programmable Lighting Effects: Choose from 20 separate user-programmable lighting effects!
  • Dimmable Brightness: Configure multiple different brightness levels for your LED’s or incandescent bulbs.
  • Decoder Lock: Feature which prevents accidental/unwanted programming while activated.
  • Airwire™ Compatible: Fully compatible with Airwire™ operation.
  • Audio Assist®: TCS exclusive auditory feedback programming system. Program your decoder without the need to memorize CV’s!
  • User-Loadable Speed Tables: Configure custom speed curves and set speed limits.
  • Throttle Modes: Choose from multiple throttle modes to meet your operating needs.
  • Proto Notch™: A WOWSound original feature which uses TCS’ exclusive auto-adjusting BEMF technology to automatically choose the active notch sound. Prototype Mode also offers dynamic sound volumes which accurately model the real-life equivalent. Also includes pre-programmed acceleration and deceleration values.

Specs

  • Interface Type: Hard-Wire, Direct-Plug (9-Pin JST)
  • Dimensions (L x W x H): 1.35″ x 0.658″ x 0.22″ or 34.29mm x 16.72mm x 5.59mm
  • Scale: HO Scale
  • Continuous/Peak: 1.3/2.0 Amp
  • Total Functions: 6
  • Function Rating: 100 mA
  • 12V Outputs: 6

Speaker Selection

  • This decoder is optimized for 8 Ω speakers (not included).
  • This decoder uses and audio amplifier capable of supplying up to 2 Watts of power. A 1 Watt minimum power rating is recommended for use with this decoder. If you are using a speaker with less than 1 Watt power rating, you must reduce your volume to prevent speaker failure or amplifier stress.
  • Speaker enclosures greatly increase speaker performance in most cases.
Product form

CD-Quality Sound: TCS’ world-renowned CD-quality sound. 16 Bits of resolution at 44.1kHz sample rate. Back EMF Load Compensation: Provides superior... Read more

SKU: TCS-1530
Barcode: 879508004847

Out of stock

$105.49

    • 30 Days Free Returns
    • Top-notch Packaging
    • 100% Secure Payments

    Description

    • CD-Quality Sound: TCS’ world-renowned CD-quality sound. 16 Bits of resolution at 44.1kHz sample rate.
    • Back EMF Load Compensation: Provides superior slow speed control and high performance under load.
    • Quiet Drive: Super-quiet motor control for “buzz” free motor performance.
    • Variable Momentum: Allows you to make custom acceleration and deceleration curves.
    • Incandescent Bulb Support: This decoder can be used with 12 Volt bulbs.
    • Function Remapping: Buttons 0 through 12 may be used to control the lighting functions of this decoder.
    • Programmable Lighting Effects: Choose from 20 separate user-programmable lighting effects!
    • Dimmable Brightness: Configure multiple different brightness levels for your LED’s or incandescent bulbs.
    • Decoder Lock: Feature which prevents accidental/unwanted programming while activated.
    • Airwire™ Compatible: Fully compatible with Airwire™ operation.
    • Audio Assist®: TCS exclusive auditory feedback programming system. Program your decoder without the need to memorize CV’s!
    • User-Loadable Speed Tables: Configure custom speed curves and set speed limits.
    • Throttle Modes: Choose from multiple throttle modes to meet your operating needs.
    • Proto Notch™: A WOWSound original feature which uses TCS’ exclusive auto-adjusting BEMF technology to automatically choose the active notch sound. Prototype Mode also offers dynamic sound volumes which accurately model the real-life equivalent. Also includes pre-programmed acceleration and deceleration values.

    Specs

    • Interface Type: Hard-Wire, Direct-Plug (9-Pin JST)
    • Dimensions (L x W x H): 1.35″ x 0.658″ x 0.22″ or 34.29mm x 16.72mm x 5.59mm
    • Scale: HO Scale
    • Continuous/Peak: 1.3/2.0 Amp
    • Total Functions: 6
    • Function Rating: 100 mA
    • 12V Outputs: 6

    Speaker Selection

    • This decoder is optimized for 8 Ω speakers (not included).
    • This decoder uses and audio amplifier capable of supplying up to 2 Watts of power. A 1 Watt minimum power rating is recommended for use with this decoder. If you are using a speaker with less than 1 Watt power rating, you must reduce your volume to prevent speaker failure or amplifier stress.
    • Speaker enclosures greatly increase speaker performance in most cases.
