ALCO Diesel

The 2-amp Econami ECO-PNP universal-style Digital Sound Decoder is suitable for a wide variety of models from HO to S scale. This decoder includes a connector to easily add a CurrentKeeper (P.N. 810140) to maintain performance over dirty track and switches. Product Specifications: Sound Profile: Diesel Dimensions: 74 x 17 x 5mm Max. Motor Stall Current: 2A Max. Function Current: 100mA (each output) Function Outputs: 6 Audio Amplifier: 2 Watt, 8-Ohm Load DCC Track Voltage: 7.5V – 22V Sound Channels: 12

Read more less

The Econami ECO-21PNEM 1-amp Digital Sound Decoder simply plugs into models equipped with an NEM-supported 21-pin socket. The ECO-21PNEM can be wired to a CurrentKeeper (P.N. 810140) to maintain performance over dirty track and switches. Product Specifications: Sound Profile: Diesel Dimensions: 30.5 x 15.5 x 6.55mm Max. Motor Stall Current: 1A Max. Function Current: 100mA (each output) Function Outputs: 6 Audio Amplifier: 2 Watt, 8-Ohm Load DCC Track Voltage: 7.5V – 22V Sound Channels: 12

Read more less

Tsunami2 meets N-Scale! The TSU-KN1 is our first plug and play Tsunami2 N-Scale decoder. Finally, you can get the Tsunami2 features you have been wanting in your N-Scale locomotives! We are excited to introduce a Plug and Play Tsunami2, N-Scale decoder and installation kit. The new TSU-KN1 is designed to fit into Kato N-Scale E, F-units, F40PH, PA and P42 locomotives. Get an easy install and the amazingly realistic sounds plus the features that all Tsunami2 decoders have to offer.   The TSU-KN1 comes with a complete installation kit ensuring an easy install. Also note that the TSU-KN1 is designed with 4 LED friendly function outputs making external resistors unnecessary! Installation kit includes: TSU-KN1 Decoder Mini Cube 3 Speaker and Baffle  Speaker Wire  Kapton Tape 2 Sunny White LEDs  Product Specifications: Dimensions: 55 x 13.8 x 3.2mm Max. Motor Stall Current: 500mA Max. Function Current: 100mA (each output) Function Outputs: 4 (LED Friendly. No resistors necessary) Audio Amplifier: 1 Watt, 8-Ohm Load DCC Track Voltage: 7.5V – 22V Sound Channels: 16 Tsunami2 Digital Sound Decoders integrate a full-featured sound system, Hyperlight™ lighting effects, Hyperdrive2™ advanced motor control, and a DCC decoder into a single package. Tsunami2 Digital Sound Decoders offer 20+ lighting effects in each model! Other popular Tsunami2 features include: Reactive Dynamic Digital Exhaust, Functioning locomotive and train brakes. We also offer a large selection of selectable sound effects including: 8 manufacturer specific prime movers, bells (12), airhorns (40+), couplers, compressors, and more!

Read more less

The TSU-2200 is a versatile Digital Sound Decoder that is suitable for a wide variety of models from HO to S scale. You will feel like you are in the cab with the amazing new features that Tsunami2 has to offer including: Reactive Dynamic Digital Exhaust, Functioning locomotive and train brakes, injectors, power reverse, and firebox flicker. We also offer a large selection of selectable sound effects including: exhaust chuffs (10), prime movers (up to 12), bells (12), Whistles (90), airhorns (40+), couplers, dynamos and more! This 2-amp, universal-style format, and includes a connector to easily add a CurrentKeeper (P.N. 810140) to maintain performance over dirty track and switches. Product Specifications: Sound Profile: ALCO Diesel Dimensions: 35 x 18 x 6mm Max. Motor Stall Current: 2A Max. Function Current: 100mA (each output) Function Outputs: 6 Audio Amplifier: 2 Watt, 8-Ohm Load DCC Track Voltage: 7.5V – 22V Sound Channels: 16

Read more less

CD-Quality Sound: TCS’ world-renowned CD-quality sound. 16 Bits of resolution at 44.1kHz sample rate. Keep-Alive®: Included on-board for smooth, stutter-free operation. Back EMF Load Compensation: Provides superior slow speed control and high performance under load. Quiet Drive: Super-quiet motor control for “buzz” free motor performance. Variable Momentum: Allows you to make custom acceleration and deceleration curves. Incandescent Bulb Support: This decoder can be used with 12 Volt bulbs. Function Remapping: Buttons 0 through 12 may be used to control the lighting functions of this decoder. Programmable Lighting Effects: Choose from 20 separate user-programmable lighting effects! Dimmable Brightness: Configure multiple different brightness levels for your LED’s or incandescent bulbs. Decoder Lock: Feature which prevents accidental/unwanted programming while activated. Airwire™ Compatible: Fully compatible with Airwire™ operation. Audio Assist®: TCS exclusive auditory feedback programming system. Program your decoder without the need to memorize CV’s! User-Loadable Speed Tables: Configure custom speed curves and set speed limits. Throttle Modes: Choose from multiple throttle modes to meet your operating needs. Proto Notch™: A WOWSound original feature which uses TCS’ exclusive auto-adjusting BEMF technology to automatically choose the active notch sound. Prototype Mode also offers dynamic sound volumes which accurately model the real-life equivalent. Also includes pre-programmed acceleration and deceleration values.   Specs Interface Type: Hard-Wire, Direct-Plug (9-Pin JST) Dimensions (L x W x H): 1.35″ x 0.658″ x 0.22″ or 34.29mm x 16.72mm x 5.59mm Scale: HO Scale Continuous/Peak: 1.3/2.0 Amp Total Functions: 6 Function Rating: 100 mA 12V Outputs: 6   Speaker Selection This decoder is optimized for 8 Ω speakers (not included). This decoder uses and audio amplifier capable of supplying up to 2 Watts of power. A 1 Watt minimum power rating is recommended for use with this decoder. If you are using a speaker with less than 1 Watt power rating, you must reduce your volume to prevent speaker failure or amplifier stress. Speaker enclosures greatly increase speaker performance in most cases.

Read more less

Blunami will change the way you enjoy the model railroading hobby! The Blunami BLU-4408The BLU-4408 is designed to wirelessly operate models with higher stall currents such as some S, O, and large scale locomotives; this decoder features easy-to-use terminal blocks for no-fault wiring and a higher audio amplifier for awesome volume, indoors or out. Blunami decoders can be operated in three different ways: DC, DCC and Wireless mode. Using the Blunami app (iOS versions 8 or later), you can operate your locomotive with incredible ease of use. You will feel like you are in the cab with the amazing new features that Tsunami2 has to offer including: Reactive Dynamic Digital Exhaust, Functioning locomotive and train brakes, injectors, power reverse, and firebox flicker. We also offer a large selection of selectable sound effects including: exhaust chuffs(10), prime movers (up to 12), bells (12), Whistles (90), airhorns (40+), couplers, dynamos and more! DYNAMIC DIGITAL EXHAUST For added realism, you’ll love our reactive Dynamic Digital Exhaust (DDE) feature. When your locomotive is traveling across flat terrain and simply maintaining speed, you will hear your locomotive chugging along. But, when the locomotive encounters a grade and the engineer applies more throttle to get the train up the hill, the engine sounds will automatically react and reflect the increase of power needed to crest the hill. DDE accomplishes this by calculating the changes in strain or load on the motor and adjusting the exhaust to appropriately simulate the work the engineer would be doing to the throttle of the engine. This gives Tsunami2 the ability to create the most realistic experience possible.HIGH QUALITY SOUND LIBRARYOur large selection of high quality sound effects include:  10 Exhaust Chuffs Up to 12 Prime Movers in each sound profile  Up to 12 Bells  90 Whistles 40+ Airhorns Additional couplers, dynamos, cab chatter and more! ADDED REALISMAdditional realism can be simulated by adding functioning locomotive and train brakes, injectors, power reverse, firebox flicker and more. EASY INSTALLATIONNo soldering required! This decoder features easy-to-use terminal blocks for no-fault wiring. This 4-amp, universal-style format decoder includes a connector to easily add a CurrentKeeper (P.N. 810140 or 810160) to maintain performance over dirty track and switches. Dimensions: 69 x 30.5 x 14mm  Max. Motor Stall Current: 4A Max. Function Current: 400mA (each output) Function Outputs: 8 Audio Amplifier: 3 Watt, 8-Ohm Load DCC Track Voltage: 7.5V – 26V Sound Channels: 16   Blunami Owner's Manual Blunami Installation Guide Blunami Steam User's Guide Blunami Diesel User's Guide Blunami Electric User's Guide   Blunami Sound Selection References: Blunami Steam-2 Sound Selection Reference Blunami EMD Sound Selection Reference Blunami EMD-2 Sound Selection Reference Blunami GE Sound Selection Reference Blunami ALCO Sound Selection Reference Blunami Baldwin & Others Sound Selection Reference Blunami Electric Sound Selection Reference   Blunami Sound Samples Blunami Steam-2 Sounds Blunami EMD Blunami EMD-2 Sounds Blunami GE Sounds Blunami ALCO Sounds Blunami Baldwin & Other Diesel Sounds Blunmai Electric Sounds SoundTraxx A true pioneer in the model train industry, SoundTraxx has been creating innovative products for the discriminating model railroader since 1990. We proudly design and manufacture our industry-best products right here in the USA, and our friendly customer support staff work side-by-side with the rest of our product team.

Read more less

CD-Quality Sound: TCS’ world-renowned CD-quality sound. 16 Bits of resolution at 44.1kHz sample rate. Back EMF Load Compensation: Provides superior slow speed control and high performance under load. Quiet Drive: Super-quiet motor control for “buzz” free motor performance. Variable Momentum: Allows you to make custom acceleration and deceleration curves. Incandescent Bulb Support: This decoder can be used with 12 Volt bulbs. Function Remapping: Buttons 0 through 12 may be used to control the lighting functions of this decoder. Programmable Lighting Effects: Choose from 20 separate user-programmable lighting effects! Dimmable Brightness: Configure multiple different brightness levels for your LED’s or incandescent bulbs. Decoder Lock: Feature which prevents accidental/unwanted programming while activated. Airwire™ Compatible: Fully compatible with Airwire™ operation. Audio Assist®: TCS exclusive auditory feedback programming system. Program your decoder without the need to memorize CV’s! User-Loadable Speed Tables: Configure custom speed curves and set speed limits. Throttle Modes: Choose from multiple throttle modes to meet your operating needs. Proto Notch™: A WOWSound original feature which uses TCS’ exclusive auto-adjusting BEMF technology to automatically choose the active notch sound. Prototype Mode also offers dynamic sound volumes which accurately model the real-life equivalent. Also includes pre-programmed acceleration and deceleration values. Specs Interface Type: Direct-Plug (21-Pin MTC) Dimensions (L x W x H): 1.28″ x 0.689″ x 0.22″ or 32.5mm x 17.5mm x 5.6mm Scale: HO Scale Continuous/Peak: 1.3/2.0 Amp Total Functions: 8 Function Rating: 100 mA 12V Outputs: 8 Speaker Selection This decoder is optimized for 8 Ω speakers (not included). This decoder uses and audio amplifier capable of supplying up to 2 Watts of power. A 1 Watt minimum power rating is recommended for use with this decoder. If you are using a speaker with less than 1 Watt power rating, you must reduce your volume to prevent speaker failure or amplifier stress. Speaker enclosures greatly increase speaker performance in most cases.

Read more less

Blunami will change the way you enjoy the model railroading hobby! The Blunami BLU-4408The BLU-4408 is designed to wirelessly operate models with higher stall currents such as some S, O, and large scale locomotives; this decoder features easy-to-use terminal blocks for no-fault wiring and a higher audio amplifier for awesome volume, indoors or out. Blunami decoders can be operated in three different ways: DC, DCC and Wireless mode. Using the Blunami app (iOS versions 8 or later), you can operate your locomotive with incredible ease of use. You will feel like you are in the cab with the amazing new features that Tsunami2 has to offer including: Reactive Dynamic Digital Exhaust, Functioning locomotive and train brakes, injectors, power reverse, and firebox flicker. We also offer a large selection of selectable sound effects including: exhaust chuffs(10), prime movers (up to 12), bells (12), Whistles (90), airhorns (40+), couplers, dynamos and more! DYNAMIC DIGITAL EXHAUST For added realism, you’ll love our reactive Dynamic Digital Exhaust (DDE) feature. When your locomotive is traveling across flat terrain and simply maintaining speed, you will hear your locomotive chugging along. But, when the locomotive encounters a grade and the engineer applies more throttle to get the train up the hill, the engine sounds will automatically react and reflect the increase of power needed to crest the hill. DDE accomplishes this by calculating the changes in strain or load on the motor and adjusting the exhaust to appropriately simulate the work the engineer would be doing to the throttle of the engine. This gives Tsunami2 the ability to create the most realistic experience possible.HIGH QUALITY SOUND LIBRARYOur large selection of high quality sound effects include:  10 Exhaust Chuffs Up to 12 Prime Movers in each sound profile  Up to 12 Bells  90 Whistles 40+ Airhorns Additional couplers, dynamos, cab chatter and more! ADDED REALISMAdditional realism can be simulated by adding functioning locomotive and train brakes, injectors, power reverse, firebox flicker and more. EASY INSTALLATIONNo soldering required! This decoder features easy-to-use terminal blocks for no-fault wiring. This 4-amp, universal-style format decoder includes a connector to easily add a CurrentKeeper (P.N. 810140 or 810160) to maintain performance over dirty track and switches. Dimensions: 69 x 30.5 x 14mm  Max. Motor Stall Current: 4A Max. Function Current: 400mA (each output) Function Outputs: 8 Audio Amplifier: 3 Watt, 8-Ohm Load DCC Track Voltage: 7.5V – 26V Sound Channels: 16   Blunami Owner's Manual Blunami Installation Guide Blunami Steam User's Guide Blunami Diesel User's Guide Blunami Electric User's Guide   Blunami Sound Selection References: Blunami Steam-2 Sound Selection Reference Blunami EMD Sound Selection Reference Blunami EMD-2 Sound Selection Reference Blunami GE Sound Selection Reference Blunami ALCO Sound Selection Reference Blunami Baldwin & Others Sound Selection Reference Blunami Electric Sound Selection Reference   Blunami Sound Samples Blunami Steam-2 Sounds Blunami EMD Blunami EMD-2 Sounds Blunami GE Sounds Blunami ALCO Sounds Blunami Baldwin & Other Diesel Sounds Blunmai Electric Sounds SoundTraxx A true pioneer in the model train industry, SoundTraxx has been creating innovative products for the discriminating model railroader since 1990. We proudly design and manufacture our industry-best products right here in the USA, and our friendly customer support staff work side-by-side with the rest of our product team.

Read more less

The TSU-4400 is designed for models with higher stall currents such as some S, O, and large scale locomotives; this decoder features easy-to-use terminal blocks for no-fault wiring and a higher audio amplifier for awesome volume, indoors or out. You will feel like you are in the cab with the amazing new features that Tsunami2 has to offer including: Reactive Dynamic Digital Exhaust, Functioning locomotive and train brakes, injectors, power reverse, and firebox flicker. We also offer a large selection of selectable sound effects including: exhaust chuffs(10), prime movers (up to 12), bells (12), Whistles (90), airhorns (40+), couplers, dynamos and more! This 4-amp, universal-style format decoder includes a connector to easily add a CurrentKeeper (P.N. STX810140) to maintain performance over dirty track and switches. Product Specifications: Sound Profile: ALCO Diesel Dimensions: 69 x 30.5 x 14mm Max. Motor Stall Current: 4A Max. Function Current: 400mA (each output) Function Outputs: 6 Audio Amplifier: 3 Watt, 8-Ohm Load DCC Track Voltage: 7.5V – 26V Sound Channels: 16

Read more less

Maximize the performance of your N scale model trains with the Digitrax DN167N18 mobile decoder. This plug-in Next18 decoder offers advanced control and smooth operation, enhancing the realism of your layout. With its compact design and easy installation, it's the perfect upgrade for your locomotives. Mobile Decoder Fits Next18 socket locomotives Plug-in Next18 connector Motor drive at connector capacity 6 FX3 Functions More Information Item # DN167N18 Brand Digitrax Scale N MSRP $36.00 TCA Grading C-10 Mint - Brand New Availability In-Stock/Restockable Manuals Instruction Sheet

Read more less

Get an easy upgrade for your Bachmann Sound Value diesel models with our newest Tsunami2 decoder! The TSU-BH1 offers 8 LED-friendly function outputs so resistors are not required for LEDs! (See the wiring diagrams under product documentation for more information). Light effects are fully remappable and offer full access to our 20+ HyperLight effects.This decoder is available in 3 sound profiles EMD, GE, and ALCO. For an easy install, simply replace the Sound Value decoder and enjoy all of the Tsunami2 features you love!This decoder is designed to replace the factory board in the following Bachmann Sound Value Diesel Models: FA-2, FB-2, S-4, E7-A, SD70ACe, ES44AC, GP30, GP38-2, GP40, GP7, and SD40-2.Fun Tsunami2 features including: Reactive Dynamic Digital Exhaust, Functioning locomotive and train brakes, injectors, power reverse, and more. We also offer a large selection of selectable sound effects including: prime movers (up to 12), bells (12), airhorns (40+), couplers, and more!This decoder includes a connector to easily add a CurrentKeeper (P.N. 810140 or 810160) to maintain performance over dirty track and switches. Product Specifications: Sound Profile: ALCO Diesel Dimensions: 97 x 16 x 7.7mm Max. Motor Stall Current: 2A Max. Function Current: 100mA (each output) Function Outputs: 8 LED-Friendly Outputs! Audio Amplifier: 2 Watt, 8-Ohm Load DCC Track Voltage: 7.5V – 22V Sound Channels: 16 Tsunami2 Digital Sound Decoders integrate a full-featured sound system, Hyperlight™ lighting effects, Hyperdrive2™ advanced motor control, and a DCC decoder into a single package. Tsunami2 Digital Sound Decoders offer 20+ lighting effects in each model! Other popular Tsunami2 features include: Reactive Dynamic Digital Exhaust, Functioning locomotive and train brakes. We also offer a large selection of selectable sound effects including: 8 manufacturer specific prime movers, bells (12), airhorns (40+), couplers, compressors, and more!

Read more less

The TSU-21PNEM8 is a 1-amp Digital Sound Decoder with 8 function outputs. It is designed for easy plug-in operation when mated to a 21-pin NEM connector. You will feel like you are in the cab with the amazing new features that Tsunami2 has to offer including: Reactive Dynamic Digital Exhaust, Functioning locomotive and train brakes, injectors, power reverse, and firebox flicker. They also offer a large selection of selectable sound effects including: exhaust chuffs(10), prime movers (up to 12), bells (12), Whistles (90), airhorns (40+), couplers, dynamos and more! The TSU-21PNEM8 can be wired to a CurrentKeeper (P.N. 810140) to maintain performance over dirty track and switches. Product Specifications: Sound Profile: ALCO Diesel Dimensions: 30.5 x 15.5 x 6.5mm Max. Motor Stall Current: 1A Max. Function Current: 100mA (each output) Function Outputs: 8 Audio Amplifier: 2 Watt, 8-Ohm Load DCC Track Voltage: 7.5V – 22V Sound Channels: 16

Read more less
